UTx325M Infrared Long-Distance Thermal Monocular
UTx325M Infrared Long-Distance Thermal Monocular
Description
The UTx325M Infrared Long-Distance Thermal Monocular is engineered for professionals who require exceptional thermal image quality and dependable long-range detection. Equipped with a 400 × 300 thermal sensor, a 25 mm manual-focus lens, and a maximum detection range of 1,318 meters, it delivers outstanding performance for wildlife observation, search and rescue, security patrols, and outdoor surveillance.
Built for demanding field conditions, the UTx325M combines advanced thermal sensitivity, onboard photo and video recording, Wi-Fi connectivity, and rugged IP67 protection in a lightweight handheld design. With 16GB of internal storage, a detachable rechargeable battery, and compatibility with the Thermal Xplorer mobile app, it provides professionals with the tools needed to detect, document, and share observations confidently.
Key Features
- 400 × 300 Thermal Sensor: Produces detailed thermal images with enhanced clarity and target recognition.
- 25 mm Manual Focus Lens: Optimized for dependable long-distance thermal observation.
- 1,318 m Detection Range: Detects standard-sized heat signatures at extended distances.
- Stadiametric Range Finder: Estimates target distance without requiring a laser rangefinder.
- Thermal Sensitivity ≤25mK: Detects subtle temperature differences for exceptional image quality.
- 0.39-Inch OLED Display: Crisp 1024 × 768 display provides bright, detailed thermal viewing.
- Wi-Fi Connectivity: Connects to the Thermal Xplorer app for live viewing and file transfers.
- Photo & Video Recording: Capture PNG images and MP4 videos directly to built-in memory.
- 16GB Built-In Storage: Save recordings without requiring external memory cards.
- IP67 Waterproof Housing: Built to withstand harsh outdoor environments and drops up to 2 meters.
Shipping
Please email us at service@omahasportsandgames.com for a delivery ETA or to confirm shipping details.
What's Included
- UTx325M Infrared Long-Distance Thermal Monocular
- Carrying case
- USB Type-C charging cable
- Lens cloth
- User manual
Why You'll Love It
The UTx325M offers the image quality and detection range professionals need for demanding outdoor applications. Its upgraded 400 × 300 thermal sensor and highly sensitive detector help distinguish heat signatures with impressive clarity over long distances. Built-in Wi-Fi, onboard recording, and internal storage make documenting field observations simple, while the rugged IP67-rated housing is designed to withstand challenging environments. The detachable rechargeable battery allows for convenient charging and extended field use. Whether you're performing security patrols, monitoring wildlife, or supporting search and rescue operations, the UTx325M delivers dependable thermal imaging performance in a compact, field-ready package.
Product Specifications
View Spec Chart
| Thermal Resolution | 400 × 300 |
|---|---|
| NETD | ≤25mK |
| Spectral Response | 8 - 14µm |
| Pixel Pitch | 12µm |
| Lens Focal Length | 25 mm |
| Field of View | 10.5° × 7.9° |
| Focus | Manual Focus |
| Refresh Rate | 50 Hz |
| Detection Range | 1,318 m |
| Range Finding | Stadiametric |
| Digital Zoom | 2x, 4x, 8x / 1.0x-8.0x continuous |
| Image Format | PNG |
| Video Format | MP4 |
| Wi-Fi | Yes |
| Mobile App | Thermal Xplorer (Android & iOS) |
| Storage | Built-in 16GB |
| Display Type | OLED |
| Display Size | 0.39 in |
| Display Resolution | 1024 × 768 |
| Battery | Detachable 3200mAh Li-ion battery (UT-M20) |
| Battery Life | ≥4 hours (Wi-Fi off) |
| Interface | USB Type-C |
| Weight | 357 g |
| Dimensions | 160 × 71.5 × 38.5 mm |
| IP Rating | IP67 |
| Drop Rating | 2 m |
| Warranty | 1 Year |
FAQ
What is the maximum detection range of the UTx325M?
The UTx325M has a maximum detection range of 1,318 meters for a standard-sized target. Actual identification distance depends on environmental conditions and target size.
Does the UTx325M include a laser rangefinder?
No. The UTx325M uses a built-in stadiametric range finder to estimate target distance.
Can I record photos and videos?
Yes. The UTx325M records PNG photos and MP4 videos directly to its built-in 16GB internal storage.
Does the monocular support Wi-Fi?
Yes. Built-in Wi-Fi allows the monocular to connect to the Thermal Xplorer app for live viewing and wireless file transfers.
Is the UTx325M built for demanding outdoor conditions?
Yes. The UTx325M features an IP67-rated housing for water and dust resistance and has been tested to withstand drops of up to 2 meters.
